GT-AX11000

Model Name
GT-AX11000

Network Standard
WiFi 6 (802.11ax)
Backwards compatible with 802.11a/b/g/n/ac Wi-Fi

Product Segment
AX11000 ultimate AX performance

AX technology
Yes

Data Rate
2.4GHz AX: 4×4 (Tx/Rx) 1024 QAM 20/40MHz, up to 1148Mbps
5G-1Hz AX: 4×4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps
5G-2Hz AX: 4×4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps

Antenna
External antenna x 8
Transmit/Receive
2.4GHz 4×4
5GHz-1 4×4
5GHz-2 4×4

Processor
1.8GHz quad-core processor

Memory
256MB NAND flash and 1GB DDR3 SDRAM

Boosts speed
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
1024-QAM high data rate
20/40/80/160 MHz bandwidth

* The 160MHz bandwidth may be unavailable in the 5GHz band in some regions / countries due to regulatory restrictions.
Operating Frequency
Tri-band Wi-Fi

Ports
RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 4, Multi-Gig Ethernet port 2.5G/1G x1
USB 3.1 Gen 1 x 2

Button
WPS Button, Reset Button, Power Button, Wireless on/off Button, Boost Key

LED Indicator
Power x 1
Wi-Fi x 2
WAN x 1
LAN x 1
USB x 2
WPS x 1
2.5G Port x 1

Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 19 V with max. 3.42 A current

Package content
GT-AX11000 Extreme Gaming Router
RJ-45 Cable
Power Adapter
Quick Start Guide
Warranty Card

AiMesh
AiMesh
Primary AiMesh router
AiMesh node

Router APP
ASUS Router APP

Game
Game Boost/acceleration
Game Radar
WTFast
ROG_First
OpenNAT (Game Profile)
Gaming port

Alexa
Support Alexa skill

IFTTT
Support IFTTT

AiProtection
AiProtection Pro
Router Security Assessment
Malicious site blocking
Two-Way IPS
Infected Device Prevention and Blocking

Parental Control
Parental Control
Parental Control Customized Internet schedule
Maximum Parental Control profile :
16
Maximum Parental Control content filter rule :
16

Traffic Control
Adaptive QoS
Bandwidth Monitor
Bandwidth limiter
Maximum Bandwidth limiter rule :
32
Traditional QoS
Maximum Traditional QoS rule :
32
Traffic Monitor
Real-time traffic monitor
Wired Traffic Monitor
Wireless Traffic Monitor
Traffic Analyzer
Traffic analysis period :
Daily, Weekly, Monthly
Website history

Wireless
IPv6
MU-MIMO
WiFi Encryption :
Open system, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise
UTF-8 SSID
Guest Network
Maximum Guest Network rule :
2.4GHz x3, 5GHz-1 x3, 5GHz2 x3
Guest Network Connection time limit
Guest Network Encryption :
Open system, WPA/WPA2-Personal
WPS
Wi-Fi MAC address filter
Maximum MAC filters :
64
Wireless scheduler
Wi-Fi Radar
Airtime fairness
RADIUS Client
Universal beamforming

WAN
Explicit beamforming
Internet connection Type :
PPPoE, PPTP, L2TP, Automatic IP, Static IP
Dual WAN
WAN Aggregation
3G/4G LTE dongle
Android tethering
Port forwarding
Maximum port forwarding rule :
64
Port triggering
Maximum port triggering rule :
32
DMZ
DDNS
NAT Passthrough :
PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay
Let’s Encrypt

LAN
DHCP Server
IGMP snooping
IPTV
LAN Link Aggregation
Manually assign IP address
Maximum manually assign IP address rule :
64

VPN
VPN Client L2TP
VPN Client OVPN
VPN Client PPTP
VPN Server IPSec
VPN Server OVPN
VPN Server PPTP
VPN Fusion

USB application
File System :
HFS+, NTFS, vFAT, ext2, ext3, ext4
Safely Remove disk
AiCloud
Download master
AiDisk
Media Server
Time Machine
Samba Server
FTP Server
Shared Folder privileges

Administration
Operating mode :
Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge
Operating system :
ASUSWRT
Free OS upgrade
Firewall
Maximum Firewall keyword filter :
32
Maximum Firewall network service filter :
32
Maximum Firewall URL filter :
64
Wake on LAN (WOL)
SSH
Configuration backup and restore
Diagnosis tools
Feedback system
System log
